Allen-Bradley 1797-IE8NF POINT I/O 8-Point Analog Input Module
The Allen-Bradley 1797-IE8NF serves as a POINT I/O 8-Point Analog Input Module crafted for industrial automation environments. This module offers dependable connectivity for analog sensors to Allen-Bradley control systems like ControlLogix and CompactLogix. It incorporates 8 analog input channels, enabling precise and agile data collection in various industrial conditions. This module is pivotal for any automation system that demands accurate data input from assorted analog devices.
Technical Specifications:
- Part Number: 1797-IE8NF
- Module Type: 8-Point Analog Input Module
- Input Type: Voltage or current input (selectable)
-
Input Range:
- Voltage Inputs: 0-10V, 0-5V, 0-1V
- Current Inputs: 4-20mA, 0-20mA
- Resolution: 16-bit
- Input Impedance: 200kΩ for voltage inputs
- Accuracy: ±0.1% of full scale for voltage and current inputs
- Sampling Rate: 4 samples per second per channel
- Power Consumption: 2.5W max
- Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
- Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)
- Certifications: UL, CE, CSA, RoHS compliant
- Dimensions: 4.8 x 3.3 x 1.5 in. (121 x 84 x 38 mm)
- Weight: 0.4 lbs (0.18 kg)
- Mounting: Panel mount or DIN rail
- Isolation: 500V RMS between channels and channel-to-ground
Key Features:
- 8 Analog Inputs: Offers 8 channels for voltage or current input, providing adaptability for various analog sensors and devices.
- High Accuracy: Featuring 16-bit resolution and ±0.1% accuracy, this module delivers precise measurements for crucial industrial tasks.
- Selectable Input Ranges: Accommodates different input ranges for both voltage and current, making it suitable for various analog devices.
- Compact Design: Its space-saving design facilitates easy integration in panel-mount or DIN rail setups, optimizing installation space.
- Real-Time Data Acquisition: The module captures data at 4 samples per second per channel, ensuring accurate real-time data acquisition for process control.
- LED Indicators: Equipped with diagnostic LED indicators for each input channel, simplifying troubleshooting and system performance monitoring.
- Seamless Integration: Engineered for effortless integration with ControlLogix and CompactLogix systems for flexible and scalable industrial automation solutions.
Applications:
- Industrial Automation: Utilized to interface analog sensors like temperature sensors, pressure sensors, and flow meters with Allen-Bradley control systems.
- Process Control: Perfect for process control applications needing monitoring of analog signals from field devices in sectors such as oil & gas, manufacturing, and utilities.
- Machine Monitoring: Suitable for machine monitoring applications, allowing real-time capture of analog data from diverse machinery to enhance system performance and efficiency.
- Factory Automation: Improves factory automation systems by delivering accurate data from analog devices to help control and refine manufacturing processes.
- Environmental Monitoring: Can be applied in environmental monitoring operations to track elements like temperature, humidity, and pressure in controlled settings.
