Allen-Bradley 1790D-T0W6

Product Description

Allen-Bradley 1790D-T0W6 – Compact and High-Performance I/O Module for Industrial Automation

The Allen-Bradley 1790D-T0W6 is an advanced CompactLogix I/O module, crafted to deliver precise control, rapid data processing, and exceptional communication within industrial automation systems. Designed for rugged settings, this remote I/O module is perfect for applications requiring real-time data exchange and solid performance in complex control environments.

Technical Specifications

• Model Number: 1790D-T0W6
• Type: CompactLogix I/O Module
• Series: 1790D (Compact I/O)
• Input Voltage: 24V DC
• Current Consumption: 350 mA
• Digital I/O Points: 16 (8 input, 8 output)
• Digital Output Voltage: 24V DC (Sourcing)
• Digital Input Voltage: 24V DC (Sinking)
• Communication Protocol: DeviceNet™
• Mounting Type: DIN rail mounting
• Environmental Ratings:
  • Operating Temperature: -20°C to 60°C (-4°F to 140°F)
  • Storage Temperature: -40°C to 85°C (-40°F to 185°F)
  • Relative Humidity: 5% to 95% (non-condensing)
• Enclosure Rating: IP20
• Dimensions: 3.5 x 3.5 x 3.2 inches (89 mm x 89 mm x 81 mm)
• Weight: 0.35 lbs (0.16 kg)
• Compliance: UL, CE, CSA, RoHS, and C-Tick
• Isolation: 1500V AC RMS (channel-to-channel)

Key Features

1. Compact and Rugged Design

The 1790D-T0W6 I/O module is engineered to fit into compact industrial control systems. Its durable construction ensures steady operation in demanding industrial settings, offering stable performance even in high-vibration or extreme conditions.

2. Versatile I/O Capabilities

This digital I/O module features 16 I/O points—8 digital inputs and 8 digital outputs—to interface with field devices like sensors, actuators, and relays. It supports 24V DC inputs and 24V DC sourcing outputs, making it suitable for various control and monitoring applications in industrial automation.

3. DeviceNet Communication

The 1790D-T0W6 module employs the DeviceNet communication protocol, allowing seamless integration into DeviceNet networks for dependable and rapid data exchange across the automation system. It supports both peer-to-peer communication and device-level communication, enabling smooth data flow between control systems and connected devices.

4. High-Speed Data Processing

With fast processing capabilities, the 1790D-T0W6 module facilitates efficient signal handling, ideal for real-time control and data acquisition. The speedy processing power boosts operational efficiency and responsiveness within automation systems.

5. Easy Integration

Optimized for swift installation, the 1790D-T0W6 offers DIN rail mounting, simplifying integration into control cabinets and panels. Its compact size and ease of installation make it an excellent choice for enhancing I/O capabilities in existing industrial control systems.

6. Environmental and Protection Features

This module is built for harsh industrial settings, with a broad operating temperature range of -20°C to 60°C (-4°F to 140°F), along with high vibration resistance and shock tolerance. Furthermore, its IP20 enclosure rating ensures protection against dust and physical contact with internal components.

Applications

The Allen-Bradley 1790D-T0W6 I/O module is suitable for the following industrial applications:

• PLC System Integration: Enhances PLC control capabilities by offering reliable digital input and output interfaces.
• Remote I/O: Perfect for distributed control systems needing local I/O processing.
• Manufacturing Automation: Controls manufacturing processes, such as assembly lines, robotics, and automated systems.
• Machine Control: Provides real-time I/O control for machine automation, ensuring fast processing and accuracy.
• Industrial Networks: Integrates smoothly into existing DeviceNet networks, expanding I/O capacity in complex automation systems.
• Building and Process Automation: Used for managing HVAC systems, lighting, and other building systems.
