ABB CA5-22E | Motor Protection Circuit Breaker
Overview
The ABB CA5-22E is a dependable motor protection circuit breaker, tailored to protect motors from overload and electrical faults. Suited for industrial use, it provides excellent performance in motor safety, extending equipment lifespan. Known for its durability, compact design, and flexible installation, the CA5 series is a top choice.
Key Features
- Model: ABB CA5-22E
- Rated Current: 22 A
- Frame Size: Compact and space-saving design
- Motor Protection: Guards against overcurrent, short circuits, and motor-related issues
- Trip Characteristics: Customizable thermal and magnetic trip settings
- Rated Voltage: Up to 690 V AC
- Temperature Range: Operates in temperatures from -5°C to +40°C
- Connection Type: Screw terminals for simple installation
- Integrated Protection: Features overload, short-circuit, and phase failure protection
- Certification: Meets international standards (IEC, UL, CE)
- Auxiliary Contacts: Optional contacts for status display
Technical Specifications
- Model Number: ABB CA5-22E
- Rated Current: 22 A
- Rated Voltage: Up to 690 V AC
- Frame Size: Designed for compact, space-saving setups
-
Protection Features:
- Overload protection
- Short-circuit protection
- Phase failure protection
- Thermal overload relay
- Mounting Type: Suitable for DIN rail or panel mounting
- Rated Frequency: 50/60 Hz
- Operating Temperature Range: From -5°C to +40°C
- Degree of Protection: IP20
- Weight: 0.7 kg
- Auxiliary Contacts: Compatible with control circuits
- Trip Type: Adjustable thermal and magnetic trip settings
Applications
- Motors: Shields industrial motors from overloads and phase loss
- Pumps and Fans: Perfect for pump and fan motor protection in HVAC systems, promoting seamless operation
- Compressors: Ensures effective protection for compressors in cooling and AC systems
- Conveyor Systems: Safeguards motors in conveyor setups, avoiding electrical failures
- Industrial Machinery: Ideal for diverse machinery needing motor protection
The ABB CA5-22E motor protection circuit breaker offers a versatile solution for industrial applications, combining compact design and advanced protection features to ensure motor safety.
